Start here
A few places to begin, from the aircraft’s story to the people who fly it.
Meet the aircraft
The R44 extends Robinson’s light-helicopter layout into a four-seat cabin. The Raven II uses a fuel-injected Lycoming IO-540 engine and retains the family’s two-blade main and tail rotors. VSKYLABS represents the Raven II for X-Plane. Its documentation describes a cockpit designed for desktop and VR interaction, a native flight model and a separately maintained product for each supported simulator generation.
Aircraft background
VSKYLABS · Read more ↗Raven II simulator editions
The product represents the fuel-injected Raven II. Separate X-Plane 11 and 12 editions are offered, with native aircraft systems and VR cockpit interaction.
R44 Raven II · VSKYLABS · X-Plane 11 · X-Plane 12
VSKYLABS · Read more ↗Into the cockpit
YouTube AB Helicopters Ltd · 1 min ·
Robinson R44 external walkaround and cockpit view
A pilot introduces an R44 during a navigation flight from Denham.
Real aircraft · Robinson R44
Watch on YouTube ↗Preview images are served by AirframeDB. Videos open on YouTube only when you choose to watch.
Meet Robinson R44
The R44 extends Robinson’s light-helicopter layout into a four-seat cabin. The Raven II uses a fuel-injected Lycoming IO-540 engine and retains the family’s two-blade main and tail rotors.
VSKYLABS represents the Raven II for X-Plane. Its documentation describes a cockpit designed for desktop and VR interaction, a native flight model and a separately maintained product for each supported simulator generation.
Robinson R44
Aircraft type designators
Use the code for the model you are flying. The linked authority lists the applicable aircraft.
History & design
Four seats, still a piston helicopter
Robinson developed the R44 during the 1980s, extending its light-helicopter concept to a four-seat cabin. The company history records FAA certification in 1992. The larger aircraft broadened the role beyond the two-seat R22 while retaining piston-engine power.
Robinson Helicopter Company · Robinson Helicopter Company history ↗Manufacturer company history, with Raven II engine identity from its current product specification
Why the Raven II name matters
The Raven II is the fuel-injected member of the family. Its IO-540 installation distinguishes it from the carbureted Raven I. Those model names matter when comparing performance or choosing a simulator aircraft: a family label alone does not establish the engine, equipment or control configuration.
Robinson Helicopter Company · Robinson R44 Raven II / Clipper II specifications ↗Manufacturer Raven II product specification; distinct from the carbureted Raven I
Systems & details
Hydraulics shape the cyclic feel
The R44 II handbook describes hydraulic servos that remove main-rotor feedback from the cyclic and collective. The light normal control feel therefore belongs to the assisted system, rather than a direct reflection of rotor loads. Loss of assistance produces much heavier controls.
Friction and centering are different
The cyclic friction knob resists movement in both axes; the collective has its own friction lever. Pedals use direct push-pull controls and an elastomeric trim spring. A simulator centering spring is an interpretation of hardware support, not a measurement of these friction devices.
Governor and autopilot have separate roles
The governor adjusts throttle to help maintain engine RPM above 80 percent. Optional HeliSAS adds a cyclic centering tendency when SAS is engaged. An R44 profile therefore needs to distinguish the basic hydraulic controls from an aircraft fitted with that optional system.
In your simulator
Systems, equipment and documentation for each developer’s aircraft.
X-Plane 11 · X-Plane 12R44 Raven II
VSKYLABS · Released
R44 Raven II
VSKYLABS · Released
Manuals & resources
Find your next read
Choose a topic for a short introduction and a link to the original source. Simulator references identify the developer and edition they cover.
Simulator documentation
Raven II simulator editionsR44 Raven II · VSKYLABS · X-Plane 11 · X-Plane 12
The product represents the fuel-injected Raven II. Separate X-Plane 11 and 12 editions are offered, with native aircraft systems and VR cockpit interaction.
Official developer / designated-store reference · checked 2026-09-14
VSKYLABS · Read the source ↗Read the original documentation from the people who created it. Manuals open on their publisher’s website.
Developer documentation
VSKYLABS Aerospace Simulations Aircraft Center: VSKYLABS Robinson R44 Raven IIVSKYLABS · Official developer / designated-store reference · checked 2026-09-14 VSKYLABS Robinson R44 Raven II. Advanced add-on for X-Plane Flight Simulator.VSKYLABS · Official developer / designated-store reference · checked 2026-09-14Type designator
ICAO Doc 8643 — aircraft type designatorsInternational Civil Aviation Organization · Public search data retrieved 2026-09-14; authority update 2026-09-03Manufacturer documentation
Robinson R44 Raven II / Clipper II specificationsRobinson Helicopter Company · R44 Raven II; manufacturer reference checked 12 October 2026 Robinson Helicopter Company historyRobinson Helicopter Company · R44 Raven II; manufacturer reference checked 12 October 2026 Robinson R44 II Pilot’s Operating HandbookRobinson Helicopter Company · R44 Raven II; manufacturer reference checked 12 October 2026Built-in force-feedback profiles
Read the documentary basis, editable starting settings and remaining questions for the aircraft you fly. Each explanation refers to the exact profile revision shown.
Catalogue programme-20261022-v1 · 2 profile choices
VSKYLABS Robinson R44 Raven II
VSKYLABS · Free and Pro · Revision 3 · Inherited starting point
X-Plane 12
VSKYLABS Robinson R44 Raven II: Hydraulic cyclic assistance motivates low supported centering.
Robinson R44
Free and Pro · Revision 1 · Partial review
X-Plane 12 · X-Plane 11
Robinson R44: Hydraulic cyclic assistance motivates low supported centering.
